Got the forms all made for the footers.Down to bed rock.This week got to order the concrete and mix with a wheel barrow.

What are the measurements (length an width)? Keep us posted as you progress

Thought u were moving to Arizona or was that for pretend

No footings?

It only needs to last as long as Bruce Does.

I'd at least remove the grass!

Looks like there will be footing to me.

Keep us posted and updated on the project Bruce.

Good deal, if ya can, bum or rent a mixer. I just poured 30 80# sacks & if not for the mixer I borrowed would've been a killer. Keep updating w/ pics, any heat or plumbing?

24x24

Footing and 8 inch wall will be poured at same time

Old school.....nice

Just found it it was much cheaper to have it poured then buy the bags and mix it myself

That will be my winter home

Are you using native rough cut for your lumber?

Yes

Can’t be, the excavation would need to be a larger foot print.

Don’t see any re rod either…?

Are them round things siting on the top soil?

18” to 24”,,,, two runs of bar and uprights l hooked into foot is correct… then two bars tied to them……
that looks like a china build.

Don't need re-rod for a footer.Was cheaper for me to have everything poured togather so I'm now going to also have the porch concrete slab poured at the same time.Going to use metal cattle panels inside of the porch pad instead of re-rod.Got to also get that ready now and have the concrete sceduled to be delivered on the 17th of June.

Yes , only example of a footing and stem I could find

Just like that but no re-rod.Same as my back addition over 20 years ago.

Save your cash on the cattle panels and spend money on excavating the top soils and compact with proper fill
Bar only makes it not settle once it start to sink after the cracking start because of improper soil handling conditions

I built commercial concrete walls and footers for around 4 years. There's a huge difference in what is required for commercial inspected work and home, non inspected, do it yourself work. A lot of the difference is because of how much load is born by the footers.

Keith

Standard residential in wa unless you do a mono pour..

AZ is almost all post tension now,,, for the most part

Billings Montana is a lot of exciting ( apx 6 feet ) big footings on crushed..

Vinke....is that a napkin or toilet paper ???

Looks legit Vink


6 " fo single story, 8 " for two story.........yepprrs

Office cuts…..

It is a piece of the highest weight printer paper you can purchase from the box stores.
This piece of paper sat outside under cover for a very short period, and absorbed moisture.
My hypothesize ….l..
The higher fiber levels of wood stock used to create this fine paper, increased the amount of particulate area for moisture to be absorbed.

Might be able to save a planet with this.
Grow toilet paper….

Only 18 inches of soil untill you hit bedrock here.No settling..Bottom of the footing is on bedrock.

No sun.That will die off

Been working on the pad area for the porch,Back at it today.The concrete pour is now scheduled for the 9th

Yup.
Then you'll have a void under slab

A little ground sterilant in precision application is a simple event to take care of any vegetation you don't want for a long time.

Not following you.What slab?The floor joices and girder will be resting on the walls with supports for the girder and floor joists underneath on the cement pads.

A Den is a room in your house, I thought. This looks like a totally separate building?.??

Some of the guys appear to have thought you were putting a concrete slab as the floor for your den, instead a wood floor, supported by concrete, with a crawl space. Their comments didn't make sense to me at first either until I figured out they didn't understand what you were building.

Keith

Can’t wait for the finished product

Once I get building it will show more clearly.Not a seperate building.Back at it today.8 more feet to go on tne form for my porch pad.

Headed into work.Getting closer.Will finish getting it ready when I get back home around noontime on Tuesday.

All ready for concrete tomorrow morning 7:30 AM

Nice !

It's too clean to be the remnants of his underwear.

Concrete is done

Did you grease your forms first?

Keith

A trip today to Bangor and got a load of plywood,nails,and building wrap.

Please tell me that is at least a tandem axle trailer and not a single.

First thing I noticed.......wow that poor trailer

Getting it done , Bruce!
....nice

I have a trailer like that. If I put that much weight on it, it would go bow legged.

Single Got the nice big tires

It is still a SINGLE axle and a single set of bearings.

It got the plywood home.

Your over due

Lol....did not do that.Smooth sailing home

That light means your tire is soft.

All off the trailer and ready.Back to work today at Baxter State Park.

Get er' done!

Looks like a 3500lb axle. Should be good!

I'm glad you made it with that load safely, FYI when you don't match the suspension and trailer to the load a burnt up bearing or blown tire is bad. It however is not the worst thing that can happen.

Start building tomorrow

Did yah get that dung pipe all insulated ...for this coming wintah ???

Yep with 6 inch layer of insulation over the top and 2 feet of gravel.

Got some work done today,Nice warm day in the 90's

Interesting framing design.

Yeah

Same design I learned how to frame houses while working on a house framing crew in Virginia.

Looking forward to seeing your progress!

I gotta ask, is your framing hanging out past the concrete?

Or is it light and shadow trickery?

Ready to stand the first wall tomorrow morning.

Getting it done! Are you working by yourself? 3/4" sheets by myself are starting to kick my butt. Currently building a butcher shop inside of my pole barn. Walls for shop are 8', barn walls are 12'. Putting 3/4" on top of ceiling joists for storage. Dreading hossing 12 sheets up there by myself on Monday.

Yep by myself.Suppose to get some help tomorrow morning lifting the wall.

Looks good be fun watching your build.

Two walls up today.A little tired,One wall to go then the roof.

So is the blue tarp going to be the permanent floor covering?

Nope, will cut it off once the roof is on.

I always put a double 2x8 with one hanging over to help keep the rain out.

Are the studs 16 inches o.c. ? They look more like 24 o.c. Do you have a code where you're at?

24 inches using true rough cut lumber.eveything is 2 inches thick ,unlike planed lumber wich is only 1 1/2 inches thick.I live in unorganized territory with no codes.

Thanks Bruce. It's looking good!

Are you required to put cripple studs to hold up your door and window headers?

That explains it….

You should have put it onn skids, then you could’ve hooked up the jeep and pulled it off the “foundation “ and towed it to deer camp.

Rained out today.Back at it next week.

A little rain won't hurt anybody! Lol
You cutting in a door from the main house or just a 24x24 den by itself??

About a 7 foot wide open opening from the main house into my den.Plus the door from outside from the new front porch.LOL....I'm to old to get wet and cold when I can just wait for better weather.Still got alot of time before fall gets here.

Nice! Keep us posted.

Looks Good

Odds and ends this afternoon.I got home from work.Visited my mother.Then odds and ends day at home.Moved the dryer vent and outside spicket to end of my house.Then took out a window that will be added later to the end of the house as well.Start framing the last wall tomorrow morning.Got to visit a grandson in Houlton at 10:00 am before heading back home and finish getting the wall framed up.

The walls are up.Roof is next.

Yep, that is the order I do them in also.

You guys are so old-school.

Had to replace a bunch of rotted wood under the front door.Back to work later today at Baxter.Next week first build the new front steps then start on the roof after another trip to the Amish for 2x6’s

How are you coming off the original house with the roof.

Looks good

have the roof go the opposite way with two valleys.Headed to the Amish to get my roofing rafters this morning.

Getting the rafters put on

Looks good. I'm more of a finish carpenter than a framer, but it always is a good feeling to be putting a roof on.

Looks good!! I bet you are a tired guy or you will be before you get it all done. I built a line shack last year about this time ad I was tired before and after I got it done. Lol I did everything myself with no help so it was up and down and back and forth a lot.

Thanks.You have that all right.I am tired.Alot of work for sure.

please dont tell folks you learned to frame here in va.

Doing well Bruce

Hahaha

That’s where I learned at Morcom’s home builders

Rafters are all on.Back to work in Baxter

Apparently there was no building code in Va.

Looking good ....I like the true sized rough sawn
