Design flaw #8216898
09/16/24 10:42 AM
09/16/24 10:42 AM
Joined: Nov 2023
NV
2
2bit Offline OP
trapper
2bit  Offline OP
trapper
2

Joined: Nov 2023
NV
Can anyone point out a major design flaw with this trap?
I had a pull out because of it.

Last edited by 2bit; 09/16/24 10:44 AM.
Re: Design flaw [Re: 2bit] #8216899
09/16/24 10:44 AM
09/16/24 10:44 AM
Joined: Oct 2009
east central WI
K
k snow Online content
trapper
k snow  Online Content
trapper
K

Joined: Oct 2009
east central WI
Are the levers hitting the sides of the pan?

Re: Design flaw [Re: 2bit] #8216900
09/16/24 10:44 AM
09/16/24 10:44 AM
Joined: Dec 2006
N.W. Iowa
T
Tactical.20 Offline
trapper
Tactical.20  Offline
trapper
T

Joined: Dec 2006
N.W. Iowa
What brand is it

Re: Design flaw [Re: 2bit] #8216902
09/16/24 10:47 AM
09/16/24 10:47 AM
Joined: Dec 2006
Rodney,Ohio
SNIPERBBB Offline
trapper
SNIPERBBB  Offline
trapper

Joined: Dec 2006
Rodney,Ohio
from the baseplate it looks like a bridger

Re: Design flaw [Re: k snow] #8216905
09/16/24 10:49 AM
09/16/24 10:49 AM
Joined: Dec 2006
La Crosse, WI
Macthediver Offline
trapper
Macthediver  Offline
trapper

Joined: Dec 2006
La Crosse, WI
Originally Posted by k snow
Are the levers hitting the sides of the pan?


My guess too is pan got wedged between levers??

Mac

"Never Forget Which Way Is Up!"


"Never Forget Which Way Is Up"

Re: Design flaw [Re: k snow] #8216906
09/16/24 10:50 AM
09/16/24 10:50 AM
Joined: Nov 2023
NV
2
2bit Offline OP
trapper
2bit  Offline OP
trapper
2

Joined: Nov 2023
NV
Yes. I was checking traps last year and one of these had the levers half cocked and the pan was fully depressed. I am going through all of them and grinding the pan to a dog bone shape. So the pan can bottom out on the frame with the levers fully engaged.

I will not disclose the brand name, my intent is not brand bashing. It is a dogless #2. The hinge point of the jaws have been filed so they open and close smoothly with no rough spots. It's been soaked in vinegar, rinsed and is now ready for dye and wax

Re: Design flaw [Re: Macthediver] #8216907
09/16/24 10:52 AM
09/16/24 10:52 AM
Joined: Nov 2023
NV
2
2bit Offline OP
trapper
2bit  Offline OP
trapper
2

Joined: Nov 2023
NV
Originally Posted by Macthediver
Originally Posted by k snow
Are the levers hitting the sides of the pan?


My guess too is pan got wedged between levers??

Mac

"Never Forget Which Way Is Up!"


Correct

Re: Design flaw [Re: 2bit] #8216909
09/16/24 10:56 AM
09/16/24 10:56 AM
Joined: Nov 2012
midland, michigan
M
midlander Offline
trapper
midlander  Offline
trapper
M

Joined: Nov 2012
midland, michigan
Originally Posted by 2bit
Yes. I was checking traps last year and one of these had the levers half cocked and the pan was fully depressed. I am going through all of them and grinding the pan to a dog bone shape. So the pan can bottom out on the frame with the levers fully engaged.

I will not disclose the brand name, my intent is not brand bashing. It is a dogless #2. The hinge point of the jaws have been filed so they open and close smoothly with no rough spots. It's been soaked in vinegar, rinsed and is now ready for dye and wax


Im not sure others would see it as brand bashing as much as they would a courtesy for those that may want to correct the problem if they own the same brand traps..?

Re: Design flaw [Re: 2bit] #8216940
09/16/24 11:42 AM
09/16/24 11:42 AM
Joined: Aug 2018
Pennsylvania
The hammer Offline
trapper
The hammer  Offline
trapper

Joined: Aug 2018
Pennsylvania
Looks like a duke number 2 judging by the jaws. Modified two dozen for a guy and quite a few would do that with the pan and levers when fired.

Re: Design flaw [Re: The hammer] #8216941
09/16/24 11:43 AM
09/16/24 11:43 AM
Joined: Oct 2009
east central WI
K
k snow Online content
trapper
k snow  Online Content
trapper
K

Joined: Oct 2009
east central WI
Originally Posted by The hammer
Looks like a duke number 2 judging by the jaws. Modified two dozen for a guy and quite a few would do that with the pan and levers when fired.


Yep, about half of my duke #2s would do that, they all got the pan narrowed down a bit.

Re: Design flaw [Re: 2bit] #8216961
09/16/24 12:07 PM
09/16/24 12:07 PM
Joined: Jan 2020
Aliceville, Kansas 45
Yukon John Offline
trapper
Yukon John  Offline
trapper

Joined: Jan 2020
Aliceville, Kansas 45
I like big b_++$, but not big pans.


Act like a blank, get treated like a blank. Insert your own blank!
Re: Design flaw [Re: 2bit] #8217021
09/16/24 01:46 PM
09/16/24 01:46 PM
Joined: Feb 2010
pa
H
hippie Offline
trapper
hippie  Offline
trapper
H

Joined: Feb 2010
pa
Those jaws are closed enough that you only lost a toe catch, but a loss none the same.


There comes a point liberalism has gone too far, we're past that point.
Re: Design flaw [Re: 2bit] #8217060
09/16/24 02:46 PM
09/16/24 02:46 PM
Joined: May 2010
The great cage state Colorado
M
Monster Toms Offline
trapper
Monster Toms  Offline
trapper
M

Joined: May 2010
The great cage state Colorado
Those long, spring pins will cause you grief at some point also.






Re: Design flaw [Re: 2bit] #8217128
09/16/24 04:20 PM
09/16/24 04:20 PM
Joined: Nov 2023
NV
2
2bit Offline OP
trapper
2bit  Offline OP
trapper
2

Joined: Nov 2023
NV
I have Bridger and Duke. I'm at work right now, so can't confirm which it is, but something to correct if you have this issue. The jaws are offset, mandatory in my state, so it was likely not a toe catch, especially considering the critter was able to have the pan completely depressed and have the levers pinch on it. I was chasing a grey fox which I eventually connected with. Quite possibly what escaped.

Last edited by 2bit; 09/16/24 04:21 PM.
Re: Design flaw [Re: 2bit] #8217136
09/16/24 04:34 PM
09/16/24 04:34 PM
Joined: Jun 2022
Manitoba
Shakeyjake Offline
trapper
Shakeyjake  Offline
trapper

Joined: Jun 2022
Manitoba
I noticed that a couple years ago while pulling the set. Mines Bridger #3 dogless.


Wind Blew, crap flew, out came the line crew
Re: Design flaw [Re: 2bit] #8217192
09/16/24 06:44 PM
09/16/24 06:44 PM
Joined: Mar 2010
SD
Boone Liane Offline
trapper
Boone Liane  Offline
trapper

Joined: Mar 2010
SD
The Bridger dogless would do that.

At least the early runs would. I had a dozen of the early early made ones that were horrible for it.

Probably the most overrated trap out there.

Re: Design flaw [Re: Shakeyjake] #8217196
09/16/24 06:51 PM
09/16/24 06:51 PM
Joined: Nov 2023
NV
2
2bit Offline OP
trapper
2bit  Offline OP
trapper
2

Joined: Nov 2023
NV
Originally Posted by Shakeyjake
I noticed that a couple years ago while pulling the set. Mines Bridger #3 dogless.


I just picked up a few dozen new Bridger #3 dogless from tman sponsor and the pan has plenty of clearance from the levers. Maybe someone noticed and corrected the issue.
